SHUTTLE-BAND

Diese Einheit wird für den Transfer von Leiterplatten von einer Leiterplattenproduktionslinie in zwei Leiterplattenproduktionslinien", von einspurig zu zweispurig betriebenen Maschinen" oder umgekehrt verwendet. Das integrierte Shuttle-Transportband bewegt sich seitlich, um sich an vor- und nachgelagerten Maschinen auszurichten. Das 7"-Farb-Touchscreen-Display ermöglicht eine einfache Bedienung auf mehreren Benutzerebenen.

advancedseries.svg
a nta910tv shuttle conveyor(1)

STANDARD FEATURES

  • Servo driven shuttle conveyor movement.
  • Automatic conveyor width adjustment.
  • 7” full colour touchscreen display.
  • Advanced graphic Human Machine Interface (HMI).
  • Multi level user acces control.
  • In,- & Output diagnostics on touchscreen display.
  • 2000 product recipes storage.
  • Ethernet connection for network interface.
  • Traversing distance max. 1500 mm.
  • Machine cunfiguration upon request.
  • Front and rear adjustable stop positions.
  • Stainless steel PCB side guide.
  • CE Certified.
a nta910tv shuttle conveyor tek

Technical drawing

OPTIONS

  • IPC-HERMES-9852 communication.
  • Automatic product change-over by Nutek leader - follower software.
  • Line Control Software ready.
  • Remotely accessible PLC.
  • Customized traversing distance (4000 mm max.)
  • OK/NG PCB seperation
  • Safety shutter at in,- and/or outlet.
  • Cantilevered input- or output conveyor (500 mm)
  • LED towerlight display for machine status
  • Alarm buzzer
  • Other options available on request
SPECIFICATIONS
Transfer height
950 mm ± 25 mm*
Colour
RAL 9002*
Flow direction
Left to right*
Fixed rail
Front*
Machine interface
IPC-SMEMA-9851*
Components clearance
Top 30 mm, bottom 30 mm
Power supply
230 VAC/50 Hz/1 Ph
Power consumption
340 VA max
Belt speed
14 m/min
Cycle time
± 14 sec. (max. 1500 mm traversing distance)
PCB edge support
3 mm
PCB thickness
0,4 - 4 mm
PCB weight
2,5 Kg (max)
* or specify
MACHINE SIZES - M
NTA 910TVM
Machine L x W x H (mm)
500 x 2300 x 1130*
Weight (Kg)
180
PCB Length (mm)
80 - 330
PCB Width (mm)
50 - 250
Fixed rail to front dim. X (mm)
256
Fixed to Fixed distance (X2)
1500 max.*
Towerlight height (Z)
2000
* Depending on specifications
MACHINE SIZES - XL
NTA 910TVXL
Machine L x W x H (mm)
653 x 2500 x 1130*
Weight (Kg)
240
PCB Length (mm)
80 - 460*
PCB Width (mm)
50 - 460*
Fixed rail to front dim. X (mm)
256
Fixed to Fixed distance (X2)
1500 max.*
Towerlight height (Z)
2000
* Depending on specifications

Download our datasheet for more specifications.
