STANDARD FEATURES
- Automatic magazine change-over.
- Automatic magazine alignment by upper and lower pneumatic clamping.
- Controlled by PLC.
- Tailor made to the magazine of your choice.
- Threshold signal to protect PCB’s in upstream oven.
- LED towerlight display for machine status.
- Selectable pitch settings.
- CE certified.
Technical drawing
OPTIONS
- Width adjustment magazine conveyors
- Additional magazine capacity
- Shorter magazine change over time (± 19-22 sec.)
- Touchscreen display
- Alarm buzzer
- Other options available on request
SPECIFICATIONS
Transfer height
950 mm ± 25 mm*
Colour
RAL 9002*
Flow direction
Left to right*
Fixed rail
Front*
Machine interface
SMEMA*
Components clearance
Top 30 mm, bottom 30 mm
Power supply
230 VAC/50 Hz/1 Ph
Power consumption
550 VA max.
Air supply
4-6 bar
Air consumption
10 ltr/min max.
PCB loading time
± 6 seconds
Magazine change-over time
± 30-40 seconds (depending on machine size)
Pitch control
1-4, 10 mm pitch
Max. total magazine weight
50 kg each
Pusher conveyor
To be ordered separately
* or specify
Total number of magazines
1
Magazine on the lifter platform.
2
Empty magazines on the upper magazine conveyor.
3
Full magazines on the lower magazine conveyor.
MACHINE SIZES - M
NTM110LM
Machine L x W x H (mm)
1870 x 820 x 1700
Weight (Kg)
235
PCB Length (mm)
80 - 330
PCB Width (mm)
70 - 250
Magazine dimensions (mm)
360 x 320 x 570
Fixed rail to front (A) (mm)
380
MACHINE SIZES - L
NTM110LL
Machine L x W x H (mm)
2335 x 1045 x 1700
Weight (Kg)
330
PCB Length (mm)
80 - 460
PCB Width (mm)
70 - 407
Magazine dimensions (mm)
535 x 530 x 570
Fixed rail to front (A) (mm)
395
MACHINE SIZES - XL
NTM110LXL
Machine L x W x H (mm)
2335 x 1095 x 1700
Weight (Kg)
400
PCB Length (mm)
80 - 460*
PCB Width (mm)
70 - 460*
Magazine dimensions (mm)
535 x 580 x 570
Fixed rail to front (A) (mm)
395
* or specify
