SPECIFICATIONS - TENSERT RACK
- Light weight, heavy duty.
- Reversible.
- Length or sideways stackable.
- Size compatible to existing magazine models.
TECHNICAL DRWAING - TENSERT RACK
OPTIONS
- Spring type stopper bars
- Card holders
PRODUCT SIZES
M1(2508)EDT-21
D = PCB width
80 - 250 mm
C = Max. PCB length
330 mm
L = Depth of magazine
355 mm
W = Width of magazine
316 mm
H = Height of magazine
565 mm
A = Outside edge to PCB slot
35 mm
B = Lower edge to PCB slot
35 mm
B' = Upper edge to PCB slot
35 mm
Max. PCB temperature (°C)
60
Weight incl. transport safety
5,2 kg
Packing unit
2
PRODUCT SIZES
M2(2503)H-EDT-11KD
D = PCB width
30 - 250 mm
C = Max. PCB length
330 mm
L = Depth of magazine
354 mm
W = Width of magazine
320 mm
H = Height of magazine
563 mm
A = Outside edge to PCB slot
34 mm
B = Lower edge to PCB slot
34 mm
B' = upper edge to PCB slot
34 mm
Max. PCB temperature (°C)
130
Weight incl. transport safety
6,5 kg
Packing unit
2
PRODUCT SIZES
M3(2505)EDT-21
D = PCB width
50 - 250 mm
C = Max. PCB length
330 mm
L = Depth of magazine
354 mm
W = Width of magazine
320 mm
H = Height of magazine
562 mm
A = Outside edge to PCB slot
33,5 mm
B = Lower edge to PCB slot
33,5 mm
B' = Upper edge to PCB slot
33,5 mm
Max. PCB temperature (°C)
60
Weight incl. transport safety
4,9 kg
Packing unit
2
